Page 58
Technical data
SLS-R HE 1402 - 4802 BLN version
SLS Shipping Operating
HE F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 F13 F14 F15 F16 Weight Weight
( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) a (mm) b (mm) c (mm) d (mm) e (mm) f (mm) g (mm) h (mm) i (mm) x (mm) y (mm)
1402 846 711 824 683 796 661 - - - - - - - - - - 4370 4520 2099 615 1208 1583 - - - - - 1000 2040
1602 853 716 832 688 804 667 - - - - - - - - - - 4420 4560 2099 615 1208 1583 - - - - - 1000 2040
1802 917 816 878 765 827 726 - - - - - - - - - - 4740 4930 2099 615 1208 1583 - - - - - 1000 2040
1902 995 847 997 850 999 851 - - - - - - - - - - 5320 5540 2099 615 1208 1583 - - - - - 1000 2040
2002 827 669 917 760 978 820 1068 911 - - - - - - - - 6730 6950 2099 615 - - 1792 1206 - - - 1010 2840
2402 842 701 936 794 999 857 1092 950 - - - - - - - - 6920 7170 2099 615 - - 1792 1206 - - - 1010 2840
2602 869 766 955 852 1013 910 1099 996 - - - - - - - - 7170 7460 2099 615 - - 1792 1206 - - - 1010 2840
2802 904 778 989 863 1047 921 1132 1006 - - - - - - - - 7340 7640 2099 615 - - 1792 1206 - - - 1010 2840
3002 985 845 1088 948 1157 1017 1260 1120 - - - - - - - - 8060 8420 2099 615 - - 1792 1206 - - - 1010 2840
3202 1252 1093 1241 1081 1233 1074 1222 1062 1210 1051 - - - - - - 11130 11520 2099 615 - - 1792 1206 1776 838 - 1020 4180
3402 1255 1094 1243 1083 1236 1075 1224 1064 1213 1053 - - - - - - 11150 11540 2099 615 - - 1792 1206 1776 838 - 1020 4180
3602 1251 1089 1262 1101 1270 1109 1282 1120 1294 1132 - - - - - - 11510 11910 2099 615 - - 1792 1206 1776 838 - 1020 4180
4202 1310 1174 1307 1171 1305 1169 1303 1167 1300 1164 - - - - - - 11800 12370 2099 615 - - 1792 1206 1776 838 - 1020 4180
4602 1352 1221 1349 1219 1348 1217 1345 1214 1342 1212 - - - - - - 12290 12820 2099 615 - - 1792 1206 1776 838 - 1020 4180
4802 1358 1225 1355 1222 1352 1219 1348 1215 1344 1211 - - - - - - 12320 12850 2099 615 - - 1792 1206 1776 838 - 1020 4180
GRAVITY
POSITION POSITION
Wei
g
ht distribution
(
k
g)
P1-P12 CENTRE OF
SLS2-en.qxp 29-06-2007 15:38 Pagina 58
