![Airwell SLS 2002 [50/77] English](/views2/1409210/page50/bg32.png)
Page 49
English
Technical data
Fans SLS STD BLN 1402 1602 1802 1902 2002 2202 2502 2702 3002 3202 3402 3602
Power supply
V-ph-Hz
400 ± 10% / 3/ 50
Number n° 4 4 6 7 8 8 8 8 12 12 12 12
Rated power per fan kW 2 2 2 2 2 2 222222
Max. absorbed current per fan
A444444444444
Fans SLS STD BLN 4202 4602 4802 5004 5404 5704 6004 6404 6804 7204 8404
Power supply
V-ph-Hz
400 ± 10% / 3/ 50
Number n° 12 14 14 16 16 20 24 24 24 24 24
Rated power per fan kW 2 2 2 2 2 222222
Max. absorbed current per fan A 4 4 4 4 4 444444
Electrical data - Fans
Fans SLS STD LN / STD-ELN 1402 1602 1802 1902 2002 2202 2502 2702 3002 3202 3402 3602
Power supply
V-ph-Hz
400 ± 10% / 3/ 50
Number n° 4 4 6 7 8 8 8 8 12 12 12 12
Rated power per fan kW 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25
Max. absorbed current per fan
A 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3
Fans SLS STD LN / STD-ELN 4202 4602 4802 5004 5404 5704 6004 6404 6804 7204 8404
Power supply
V-ph-Hz
400 ± 10% / 3/ 50
Number n° 12 14 14 16 16 20 24 24 24 24 24
Rated power per fan kW 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25
Max. absorbed current per fan A 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3
Fans SLS HE BLN 1402 1602 1802 1902 2002 2402 2602 2802 3002 3202 3402 3602
Power supply
V-ph-Hz
400 ± 10% / 3/ 50
Number n° 6 6 8 8 8 10 10 10 12 12 12 12
Rated power per fan kW 2 2 2 2 2 2 222222
Max. absorbed current per fan
A444444444444
Fans SLS HE BLN 4202 4602 4802 4804 5204 5604 6004 6404 6804 7204 7804 8404
Power supply
V-ph-Hz
400 ± 10% / 3/ 50
Number n° 16 16 16 20 20 20 24 24 24 24 24 24
Rated power per fan kW 2 2 2 2 2 2 222222
Max. absorbed current per fan
A444444444444
Fans SLS HE LN/ELN 1402 1602 1802 1902 2002 2402 2602 2802 3002 3202 3402 3602
Power supply
V-ph-Hz
400 ± 10% / 3/ 50
Number n° 6 6 8 8 8 10 10 10 12 12 12 12
Rated power per fan kW 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25
Max. absorbed current per fan
A 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3
Fans SLS HE LN/ELN 4202 4602 4802 4804 5204 5604 6004 6404 6804 7204 7804 8404
Power supply
V-ph-Hz
400 ± 10% / 3/ 50
Number n° 16 16 16 20 20 20 24 24 24 24 24 24
Rated power per fan kW 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25 1,25
Max. absorbed current per fan
A 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3 2,3
SLS2-en.qxp 29-06-2007 15:38 Pagina 49
