![Airwell SLS 1402 [60/77] English](/views2/1409210/page60/bg3c.png)
Page 59
English
Technical data
SLS-R HE 1402 - 4802 LN/ELN version
SLS Shipping Operating
HE F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 F13 F14 F15 F16 Weight Weight
( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) ( kg ) a (mm) b (mm) c (mm) d (mm) e (mm) f (mm) g (mm) h (mm) i (mm) x (mm) y (mm)
1402 876 717 855 690 827 669 - - - - - - - - - - 4490 4640 2099 615 1208 1583 - - - - - 990 2040
1602 885 723 864 696 837 675 - - - - - - - - - - 4540 4680 2099 615 1208 1583 - - - - - 990 2040
1802 948 823 910 773 860 735 - - - - - - - - - - 4860 5050 2099 615 1208 1583 - - - - - 990 2040
1902 1026 854 1028 857 1031 859 - - - - - - - - - - 5440 5660 2099 615 1208 1583 - - - - - 990 2040
2002 794 731 885 822 946 883 1036 973 - - - - - - - - 6850 7070 2099 615 - - 1792 1206 - - - 1000 2850
2402 807 765 900 858 963 921 1056 1014 - - - - - - - - 7040 7290 2099 615 - - 1792 1206 - - - 1000 2850
2602 830 834 916 920 973 978 1059 1064 - - - - - - - - 7290 7580 2099 615 - - 1792 1206 - - - 1000 2850
2802 863 846 949 932 1006 989 1092 1075 - - - - - - - - 7460 7760 2099 615 - - 1792 1206 - - - 1000 2850
3002 939 920 1042 1024 1111 1093 1215 1196 - - - - - - - - 8180 8540 2099 615 - - 1792 1206 - - - 1000 2850
3202 1277 1103 1262 1088 1252 1078 1237 1064 1222 1049 - - - - - - 11250 11640 2099 615 - - 1792 1206 1776 838 - 1020 4190
3402 1280 1105 1265 1090 1255 1081 1241 1066 1226 1051 - - - - - - 11270 11660 2099 615 - - 1792 1206 1776 838 - 1020 4190
3602 1276 1100 1284 1108 1289 1114 1298 1122 1306 1130 - - - - - - 11630 12030 2099 615 - - 1792 1206 1776 838 - 1020 4190
4202 1334 1184 1328 1178 1324 1174 1318 1168 1312 1162 - - - - - - 11920 12490 2099 615 - - 1792 1206 1776 838 - 1020 4190
4602 1376 1232 1370 1226 1366 1222 1360 1216 1354 1210 - - - - - - 12410 12940 2099 615 - - 1792 1206 1776 838 - 1020 4190
4802 1383 1236 1376 1229 1371 1224 1364 1217 1357 1210 - - - - - - 12440 12970 2099 615 - - 1792 1206 1776 838 - 1020 4190
GRAVITY
POSITION POSITION
Wei
g
ht distribution
(
k
g)
P1-P12 CENTRE OF
SLS2-en.qxp 29-06-2007 15:38 Pagina 59
