Page 12
Product Description
2.3 Refrigeration Circuits
Units AQL 20-80
OIL EQUALIZER
Components:
1 Compressors C1/C2
2 Condenser
3 Dehydrating filter
4 Liquid lamp
5 Expansion valve
6 Plate-type exchanger
7 Safety valve (only for units 40-80)
Safety & Control Devices:
CPT High-pressure service outlet
DIS Outlet temperature probe
EPT Low-pressure service outlet
EWT Entering water temperature probe
FH1 Pressure switch
FPC Condensing pressure transducer
FPE Evaporation pressure transducer
LWT Leaving water temperature probe
P Differential pressure switch, water side (only for units 20-35)
FS Electrical flow switch (optional, for units 20-35)
WATER
COLLECTOR
