Airwell AQL 50 [43/63] Trouble shooting
![Airwell AQL 50 [43/63] Trouble shooting](/views2/1409371/page43/bg2b.png)
Page 42
Trouble Shooting
Fault
Low pressure alarm. The unit
stops.
The high pressure switch has
tripped. The unit stops.
The liquid line is too high.
The liquid line is covered
with hoar-frost.
The fans can not rotate.
The thermal refrigerating
power has decreased.
The heater of the refrigerant
/ circulating fluid is not
working.
The temperature of the circu-
lating fluid is poorly checked
or not checked at all.
The fluid is only poorly
circulating.
The unit is not working
and the low flow rate
alarm has tripped.
The refrigerant is leaking.
Low charge.
Faulty pressure switch.
The pressure switch is malfunctioning.
The delivery valve is partially closed.
There are non condensables in the circuit.
The fans of the refrigerant/air exchanger are
not working.
Low charge.
The valve of the liquid line is partially closed.
The dryer filter is clogged.
Problems in the electrical circuit.
The internal thermal switches have tripped.
Faulty compressor.
The air/refrigerant exchanger is clogged.
Low charge.
The connection threshold is out of calibration.
The heater circuit has been interrupted.
The control thermostat is out of calibration.
The fluid thermal head is wrong.
The electronic control system is malfunction-
ing.
Air in the hydraulic circuit.
Deposits or impurities in the refrigerant / cir-
culating fluid exchanger
No circulation
The flow switch is not working.
The differential pressure switch is not work-
ing.
The fluid side of the exchanger is dirty.
Identify and eliminate the leakage.
Top up the charge.
Replace the pressure switch.
Check the pressure switch and replace it, if required.
Open the valve completely and replace it, if required.
Discharge the circuit.
Check the motors and the connections. Repair and/or re-
place, where required.
Identify and eliminate what has caused the charge to de-
crease.
Check the opening of the valve.
Replace the filter cartridge.
Check all connections.
Contact an Itelco-Clima Authorised Service Centre.
Contact an Itelco-Clima Authorised Service Centre.
Clean the exchanger and the circuit chemically.
Clean the batteries of the exchanger.
Top up the charge.
Check the calibration on the control panel.
Check the heater and replace it, if required.
Check the calibration on the control panel.
Check the fluid flow rate and content.
Contact an Itelco-Clima Authorised Service Centre.
Use the vent valves to discharge air.
Backwash the exchanger.
Check the pumps.
Make sure the flow switch is properly working.
Make sure the differential pressure switch is properly working.
Probable Cause Remedy
