Page 13
Product Description
English
WATER
COLLECTOR
OIL EQUALIZER
Units AQL 90-130
Safety & Control Devices:
CPT High-pressure service outlet
DIS Outlet temperature probe
EPT Low-pressure service outlet
EWT Entering water temperature probe
FH Pressure switch
FPC Condensing pressure transducer
FPE Evaporation pressure transducer
LWT Leaving water temperature probe
FS Electrical flow switch
Components:
1 Compressors C1/C2
2 Condenser
3 Dehydrating filter
4 Liquid lamp
5 Expansion valve
6 Plate-type exchanger
7 Silencer
8 Ball cock
