Indesit IWSC 51052A — установка и подключение стиральной машины: руководство по безопасности [27/36]

p inDesiT Connecting the drain hose Connect the drain hose without bending it to a drainage duct or a wall drain located at a height between 65 and 100 cm from the floor Do not use extension cords or multiple sockets GB The cable should not be bent or compressed The power supply cable must only be replaced by authorised technicians Warning The company shall not be held responsible in the event that these regulations are not respected The first wash cycle alternatively rest it on the side of a washba sin or bathtub faste ning the duct supplied to the tap see figure The free end of the hose should not be underwater We advise against the use of hose extensions if it is absolutely necessary the extension must have the same diameter as the original hose and must not exceed 150 cm in length Electrical connections Before plugging the appliance into the electricity socket make sure that Once the appliance has been installed and before you use it for the first time run a wash cycle with detergent and no laundry using the wash cycle 2 Technical data Model IWSC51052A Dimensions width 59 5 cm height 85 cm depth 42 cm Capacity from 1 to 5 kg Electrical connections please refer to the technical data plate fixed to the machine Water connection maximum pressure 1 MPa 10 bar minimum pressure 0 05 MPa 0 5 bar drum capacity 40 litres Spin speed up to 1000 rotations per minute the socket is earthed and complies with all applicable laws the socket is able to withstand the maximum power load of the appliance as indicated in the Technical data table see opposite the power supply voltage falls within the values indicated in the Technical data table see opposite the socket is compatible with the plug of the washing machine If this is not the case repla ce the socket or the plug The washing machine must not be installed outdoors even in covered areas It is extremely dangerous to leave the appliance exposed to rain storms and other weather conditions Test wash cycles in ac cordance with Programme 6 Cotton Eco 60 regulations Programme 6 Cotton Eco 40 1061 2010 and 1015 2010 a This appliance conforms to the following EC Directives 2004 108 CE Electroma gnetic Compatibility 2012 19 EU WEEE 2006 95 EC Low Voltage When the washing machine has been installed the electricity socket must be within easy reach 27
