Sharp ANPR1000H [103/109] An pr1000h an pr1000hr
![Sharp ANPR1000H [103/109] An pr1000h an pr1000hr](/views2/1410345/page103/bg67.png)
AN-PR1000H/AN-PR1000HR
14
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[11] CABINET PARTS 1
201 GBOXSA144AW01 CW Rack Unit Ass'y
202 CCABA6613AW01 AR Front Frame Ass'y
203 CWAKPA026AW01 AR Woofer Grill Ass'y
204 CWAKPA027AW01 AN Tweeter Grill Ass'y
205 CWAKPA028AW01 AR Subwoofer Net Ass'y
206 HDECQA293AWSA AK Decoration Panel
207 LHLDZA141AWZZ AF Holder, FL Display
208 PSHEGA012AWZZ AE Felt, Anti Slip
209 RSP-ZA208AWZZ BB Subwoofer
210 RSP-ZA209AWZZ AX Woofer
211 RSP-ZA210AWZZ AR Tweeter
601 LX-EZA015AWF8 AD Screw, Special
602 LX-EZA016AWF8 AB Screw, Special
603 LX-JZA010AWF7 AD Screw, M3x12mm
604 XEBY726P10000 AA Screw, M2.6 X10mm
605 XJBY730P08000 AA Screw, M3 X8mm
606 XMPY840P12000 AB Screw, M4x12m
