Sharp ANPR1000H [6/109] Description of error messages
![Sharp ANPR1000H [6/109] Chapter 2 adjustments](/views2/1410345/page6/bg6.png)
AN-PR1000H/AN-PR1000HR
2 – 1
CD-ES700/CD-ES77CD-ES700/CD-ES77Service ManualCD-ES700/CD-ES77MarketE
CHAPTER 2. ADJUSTMENTS
[1] Description Of Error Messages
* For other error messages using STANDBY LED, refer to the corresponding pages.
Error message Cause Solution
“ERR 01”
(Appears for 2 seconds and then the system
goes standby.)
• Rotation stop of the fan motor • Check if the fan motor cord is inserted
properly and the fan motor is not locked.
“ERR 02”
(When this error is not detected, the initial
display appears.)
• Error in the ICM6 (CS49510) control • Unplug the AC power cord and turn on
power again.
• Check the line connected between ICM6
and ICM7.
“ERR 03”
(When this error is not detected, the initial
display appears.)
• Internal communication error of the system
[ICA1 (WM8775) or ICM3 (CS8416CN)]
• Unplug the AC power cord and turn on
power again.
• Check the line connected among ICA1,
ICM3, ICM8 and ICM7.
“ERR 07”
(When this error is not detected, the initial
display appears.)
• Internal communication error of the system
[ICM10 (LC750512)]
• Unplug the AC power cord and turn on
power again.
• Check the line connected between ICM10
and ICM7.
“ERR 80”
(When this error is not detected, the initial
display appears.)
• Internal data read access error of ICM8
(CAT24WC05YI)
• Check EEPROM data.
• Replace EEPROM IC (ICM8).
