AN-PR1000H/AN-PR1000HR
2 – 6
[7] Tuner Test Mode
Outline
This Test Mode control are same with Normal Power-ON, only
Power-ON in TUNER function.
After Power-ON the operation and display are same but the TUNER
preset already memory as table below.
TEST Mode Operation
Set will Power-ON same process like user Power-ON, but direct to
TUNER Function Preset No. 1 of table below.
Set Preset Memory will be set as below table.
Key operation after Power ON are same with User Power-ON.
* When Test Mode end, Tuner Preset Memory will be initialize.
Others Memory initialize is not neccesry.
[8] ASPM Test Mode (For EU Destination)
Outline
At Tuner RDS ASPM operation need to be confirm for EU(H) model
only.
Power-ON in TUNER function, and scanning frequency from
105.00MHz - 108.00MHz.
And RDS station Preset Memory maximum 3 station.
TEST Mode Operation
Power ON in TUNER Function 106.50MHz FM Stereo Band. At
same time Only Preset No. ch1 - ch3 leave blank and all ch4 - ch40
memory at 87.50MHz FM Stereo Band.
With the press of ASPM key, ASPM operation will start at
105.00MHz frequency.
If RDS station received Preset will memory from ch1. (There is no
need to memory PS name in ASPM Test Mode. If preset change
during Test Mode Frequency will be display first)
Scan will stop after reach frequency 108.00MHz, and return to
frequency 106.50MHz FM Stereo.
To confirm Memory content display will show Preset Number and
frequency for ch1until ch3. After display are confirmed frequency will
return to 106.50MHz FM STEREO. (Display method same with
Tuner display during Normal POWER ON.)
If ASPM key is press again, ASPM operation will start from 2 untill
5.
While scanning if 3 station memorized, Scanning will stop and
operation 4 and 5 will take place.
Afterward, even if ASPM key input detect ASPM operation will not be
execute. "__END__" displayed and operation canceled.
Additional
Other then above, operation for ASPM are same with User
operation. So, when 1st time scan with same PI code Station with
most strong signal will be memory and will not be memory many
time. For 2nd and more station with same frequency will not be
memory.
But, if different station with same PI code (same PI with different
frequency station), station one with most strong signal will be
memory.
So, station that already memorized before scan will be ignore.
Therefore, even station with same same PI code after 3 times ASPM
scan, It is possible that, 3 station will be memorized in Signal Strong
order.
After Test Mode end only Tuner preset memory will be reset and set
to default. Ohers Memory, no need to be initialize.
50K/9K
EU㧔H㧕
Destination
P1 87.50M
Preset Memory No.
SPAN
106.00MP4
98.00MP5
108.00MP2
90.00MP3
