36
37
EN
USING YOUR DYSON APPLIANCE
PLEASE READ THE ‘IMPORTANT SAFETY INSTRUCTIONS’ IN THIS DYSON
OPERATING MANUAL BEFORE PROCEEDING.
DOCKING STATION INSTALLATION
• Unpack the docking station, plug and installation leaflet.
• Select the location for the docking station and ensure that there is no pipework
(gas, water or air), electrical cables, wires or ductwork directly behind the
mounting location.
• Follow the instructions on the installation leaflet.
• Click the attachments into place.
• Place the appliance in the docking station.
• Plug in the docking station and turn on to charge.
• Your appliance will need to be fully charged before first use.
The docking station must be mounted in accordance with regulations and
applicable codes/standards (state and local laws may apply).
Dyson recommends the use of protective clothing, eyewear and materials when
installing the docking station.
VACUUMING
• Remove the appliance from the docking station.
• Check that the underside of the cleaner head or tool is clean and free from foreign
objects that may cause damage.
Before vacuuming your flooring, rugs and carpets, check the manufacturer’s
recommended cleaning instructions.
The brush bar on the appliance can damage certain carpet types and floors. Some
carpets will fuzz if a rotating brush bar is used when vacuuming. If this happens, we
recommend vacuuming without the motorised floor tool and consulting with your
flooring manufacturer.
LIGHTS DURING CHARGING
LIGHTS DURING USE
LIGHTS DIAGNOSTICS
FILTER AND BLOCKAGE INDICATOR LEDS
EMPTYING THE CLEAR BIN
• Empty as soon as the dirt reaches the level of the MAX mark – do not overfill.
• Ensure that the appliance is disconnected from the charger before emptying the
clear bin. Be careful not to pull the 'ON' trigger.
• Avoid pulling the 'ON' trigger when emptying.
• Remove the wand by pressing the red wand release button and pulling away from
the bin.
• To release the dirt:
– Hold the appliance with the bin in a downwards position.
– Firmly push the red bin release button.
– The bin will slide down, cleaning the shroud as it goes.
– The bin base will then open.
– The bin base will not open if the red button is not pushed down fully.
To minimise dust/allergen contact when emptying, encase the clear bin tightly in a
plastic bag and empty. Remove the clear bin carefully from the bag. Seal the bag
tightly, dispose as normal.
CLEANING THE CLEAR BIN (OPTIONAL)
If it is necessary to clean the clear bin:
• Follow the instructions in the 'Emptying the clear bin' section.
• Press the red button located on the bin runner to release the bin and slide the bin
off the runner.
• Clean the clear bin with a damp cloth only.
• Ensure that the clear bin and seals are completely dry before replacing.
• To refit the clear bin:
– Insert the spine on to the bin runner.
Close the clear bin by pushing the bin base upwards until the clear bin and bin base
click into place.
The clear bin is not dishwasher safe and the use of detergents, polishes or air
fresheners to clean the clear bin is not recommended as this may damage
your appliance.
FILTER AND BLOCKAGE INDICATOR LEDS
Your appliance has two indicator lights that will help alert you that simple
maintenance steps are needed.
• The filter indicator will flash intermittently when the filter unit is not fitted correctly.
Follow the instructions on how to refit the filter unit in the 'Washing the filter unit'
section.
• The filter indicator will light continuously when the filter unit needs washing. Follow
the instructions on how to wash the filter unit in the 'Washing the filter unit' section.
• The blockage Indicator LED will light if there is a blockage. Follow the instructions
on how to clear blockages in the 'Looking for blockages' section.
WASHABLE PARTS
Your appliance has washable parts, which require regular cleaning. Follow the
instructions below.
WASHING THE FILTER UNIT
Check and wash the filter unit, according to the instructions, to
maintain performance.
• Remove the filter unit by twisting anticlockwise to the open position. Gently pull
away from the appliance.
• Wash the inside of the filter unit first; hold it upright under the cold water tap and
agitate using a rotating motion.
• Wash the outside of the filter unit; fill the unit with cold water, place your hand over
the open end and shake gently.
• Repeat washing the inside and outside of the filter unit until the water runs clear.
• Gently tap the filter unit to remove any excess water and leave to dry with the filter
end down.
• Leave the filter unit to dry completely for a minimum of 24 hours.
• Check that the filter unit is completely dry.
• To refit, return the filter unit to the open position and twist clockwise until it clicks
into place.
The filter unit may require more frequent washing if vacuuming fine dust or using
mainly maximum suction.
Do not put the filter unit in a dishwasher, washing machine, tumble dryer, oven,
microwave or near a naked flame.
Charging, low charge
Charging, medium charge
Charging, nearly full
Fully charged
High level of charge
Medium level of charge
Low level of charge
Empty, needs charging
Battery fault-call Dyson Helpline
Main body fault-call Dyson Helpline
Charger fault-call Dyson Helpline
Blockage indicator
Filter unit not fitted correctly
See battery section
Filter unit requires washing
BLOCKAGES – AUTOMATIC CUT-OUT
• This appliance is fitted with an automatic cut-out.
• If any part becomes blocked the appliance may automatically cut out.
• This will happen after the motor pulses a number of times (i.e switches on and off in
quick succession) and the blockage indicator LED will illuminate.
• Leave to cool down before looking for blockages.
• Ensure that the appliance is disconnected from the charger before looking for
blockages. Failure to do so could result in personal injury.
• Clear any blockage before restarting.
• Refit all parts securely before using.
• Clearing blockages is not covered by your guarantee.
LOOKING FOR BLOCKAGES
The motor will pulse and the blockage indicator LED will illuminate when there is a
blockage. Please follow the instructions below to locate the blockage:
• Ensure that the appliance is disconnected from the charger before looking for
blockages. Be careful not to pull the ‘ON’ trigger.
• Do not operate while checking for blockages. Doing so could result in
personal injury.
• Beware of sharp objects when checking for blockages.
• To check for blockages in the main body of the appliance, remove the clear
bin following the instructions in the 'Cleaning the clear bin' section and remove
the blockage.
• If you cannot clear an obstruction from the cleaner head, you may need to remove
the brush bar. Use a coin to unlock the fastener, slide the brush bar out of the
cleaner head and remove the obstruction. Replace the brush bar and secure it by
tightening the fastener. Ensure that it is fixed firmly before operating the appliance.
• This product has carbon fibre brushes. Take care if coming into contact with
them, as they may cause minor skin irritation. Wash your hands after handling
the brushes.
• Refit all parts securely before using.
• Clearing blockages is not covered by your guarantee.
CHARGING AND STORING
• This appliance will switch ‘OFF’ if the battery temperature is below 3°C
(37.4°F). This is designed to protect the motor and battery. Do not charge the
appliance and then move it to an area with a temperature below 3°C (37.4°F) for
storage purposes.
• To help prolong battery life, avoid recharging immediately after a full discharge.
Allow to cool for a few minutes.
• Avoid using the appliance with the battery flush to a surface. This will help it run
cooler and prolong battery run time and life.
BATTERY SAFETY INSTRUCTIONS
• If the battery needs replacing please contact the Dyson Helpline.
• Use only Dyson chargers for charging this Dyson appliance.
• The battery is a sealed unit and under normal circumstances poses no safety
concerns. In the unlikely event that liquid leaks from the battery, do not touch the
liquid and observe the following precautions:
– Skin contact – can cause irritation. Wash with soap and water.
– Inhalation – can cause respiratory irritation. Expose to fresh air and seek
medical advice.
– Eye contact – can cause irritation. Immediately flush eyes thoroughly with water
for at least 15minutes. Seek medical attention.
– Disposal – wear gloves to handle the battery and dispose of immediately,
following local ordinances or regulations.
CAUTION
The battery used in this device may present a risk of fire or chemical burn if
mistreated. Do not disassemble, short contacts, heat above 60°C(140°F), or
incinerate. Keep away from children. Do not disassemble and do not dispose of
in fire.
ONLINE SUPPORT
• For online help, general tips, videos and useful information about Dyson.
www.dyson.com/support
DISPOSAL INFORMATION
• Dyson products are made from high grade recyclable materials. Recycle
where possible.
• The battery should be removed from the product before disposal.
• Dispose of or recycle the battery in accordance with local ordinances
or regulations.
• Dispose of the exhausted filter unit in accordance with local ordinances
or regulations.
• This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the environment
or human health from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources. To return your used
device, please use the return and collection systems or contact the retailer where
the product was purchased. They can take this product for environmentally
safe recycling.
DYSON CUSTOMER CARE
THANK YOU FOR CHOOSING TO BUY A DYSON APPLIANCE.
After registering your 2year guarantee, your Dyson appliance will be covered for
parts and labour for 2years from the date of purchase, subject to the terms of the
guarantee. If you have any queries regarding your Dyson appliance, visit www.
dyson.co.uk/support (UK) or www.dyson.ie/support (ROI) for online help, general
tips and useful information about Dyson.
Alternatively, you can call the Dyson Helpline with your serial number and details of
where/when you bought the appliance.
If your Dyson appliance needs a repair, call the Dyson Helpline so we can discuss
the available options. If your Dyson appliance is under guarantee, and the repair is
covered, it will be repaired at no cost.
PLEASE REGISTER AS A DYSON APPLIANCE OWNER
The guarantee for this product is 2 years from the the date of purchase. Please
register your guarantee within 30 days of your purchase date. To help us ensure
that you receive prompt and efficient service, please register immediately after
purchase. Please keep the receipt showing the date of purchase.
There are three ways to do this:
• Online at www.dyson.com/register
• Telephone the Dyson Helpline on 08002980298 (UK) or 014757109 (ROI).
• Complete the enclosed form and post it to us.
By registering online or by phone you will:
• Protect your investment with a two year parts and labour guarantee
• Receive helpful tips on using your machine
• Get expert advice from the Dyson helpline
• Be the first to hear about our latest inventions
• Registering only takes a few minutes and all you need is your serial number.
LIMITED 2 YEAR GUARANTEE
TERMS AND CONDITIONS OF THE DYSON 2 YEAR LIMITED GUARANTEE
WHAT IS COVERED
• The repair or replacement of your Dyson appliance (at Dyson’s discretion) if
it is found to be defective due to faulty materials, workmanship or function
within 2 years of purchase or delivery (if any part is no longer available or out of
manufacture Dyson will replace it with a functional replacement part).
• Where this appliance is sold outside of the EU, this guarantee will only be valid if the
appliance is used in the country in which it was sold.
• Where this appliance is sold within the EU, this guarantee will only be valid (i) if the
appliance is used in the country in which it was sold or (ii) if the appliance is used in
Austria, Belgium, France, Germany, Ireland, Italy, Netherlands, Spain or the United
Kingdom and the same model as this appliance is sold at the same voltage rating in
the relevant country.
WHAT IS NOT COVERED
Dyson does not guarantee the repair or replacement of a product where a defect is
the result of:
• Accidental damage, faults caused by negligent use or care, misuse, neglect,
carelessness or operation or handling of the appliance which is not in accordance
with the Dyson Operating Manual.
• Use of the appliance for anything other than normal domestic household purposes.
• Use of parts not assembled or installed in accordance with the instructions
of Dyson.
• Use of parts and accessories which are not genuine Dyson components.
• Faulty installation (except where installed by Dyson).
• Repairs or alterations carried out by parties other than Dyson or its
authorised agents.
• Blockages – please refer to the Dyson Operating Manual for details of how to look
for and clear blockages.
• Normal wear and tear (e.g. fuse, brush bar etc.).
• Use of this appliance on rubble, ash, plaster.
• Reduction in battery discharge time due to battery age or use (where applicable).
If you are in any doubt as to what is covered by your guarantee, please contact the
Dyson helpline.
SUMMARY OF COVER
• The guarantee becomes effective from the date of purchase (or the date of delivery
if this is later).
• You must provide proof of (both the original and any subsequent) delivery/purchase
before any work can be carried out on your Dyson appliance. Without this proof,
any work carried out will be chargeable. Keep your receipt or delivery note.
• All work will be carried out by Dyson or its authorised agents.
• Any parts which are replaced by Dyson will become the property of Dyson.
• The repair or replacement of your Dyson appliance under guarantee will not extend
the period of guarantee.
• The guarantee provides benefits which are additional to and do not affect your
statutory rights as a consumer.
IMPORTANT DATA PROTECTION INFORMATION
When registering your Dyson appliance:
• You will need to provide us with basic contact information to register your appliance
and enable us to support your guarantee.
• When you register, you will have the opportunity to choose whether you would like
to receive communications from us. If you opt-in to communications from Dyson,
we will send you details of special offers and news of our latest innovations. We
never sell your information to third parties and only use information that you share
with us as defined by our privacy policies which are available on our website:
privacy.dyson.com.
DE/AT/CH
BENUTZUNG IHRES DYSON GERÄTES
BITTE LESEN SIE DEN ABSCHNITT „WICHTIGE SICHERHEITSHINWEISE“ IN
DIESER DYSON BEDIENUNGSANLEITUNG, BEVOR SIE DAS GERÄT BENUTZEN.
MONTAGE DER WANDHALTERUNG
• Ladehalterung, Stecker und Montageanleitung aus der Verpackung entnehmen.
• Wählen Sie für die Ladehalterung einen Standort aus und stellen Sie sicher, dass
direkt hinter dem Montageort keine Leitungen (Gas, Wasser oder Luft), Stromkabel,
Drähte oder Rohre verlaufen.

Содержание

Похожие устройства

Скачать
