-60-
Note:
● The premise for single rule taking effect is that the bandwidth of the interface for this rule is
sufficient and not used up.
● It is impossible to satisfy all the guaranteed bandwidth if the total guaranteed bandwidth specified
by all Bandwidth Control rules for certain interface exceeds the physical bandwidth of this
interface.
4.5.3 Session Limit
The amount of TCP and UDP sessions supported by the Router is finite. If there are some local hosts
transmitting too many TCP and UDP sessions to the public network, the communication quality of the
other local hosts will be affected, thus it is necessary to limit the sessions of those hosts.
4.5.3.1 Session Limit
On this page, you can configure the session limit to specified PCs.
Choose the menu Advanced→Session Limit→Session Limit to load the following page.
Figure 4-29 Session Limit
The following items are displayed on this screen:
¾ General
Enable Session
Limit:
Check here to enable Session Limit, otherwise all the Session Limit
entries will be disabled.
