-71-

Figure 4-37 ARP Scanning

Enter the start and the end IP addresses in the Scanning IP Range field. Then click the <Scan> button,

the Router will scan all the active hosts within the scanning range and display the result in the list.

The entries displayed on the List of Scanning Result do not mean the IP and MAC addresses are

already bound. The current status for the entry will display in the “Status” field.

--- Indicates that the IP and MAC address of this entry is not bound and may be

replaced by error ARP information.

Indicates that this entry is imported to the list on IP-MAC Binding page, but not

effective yet.

Indicates that the IP and MAC address of this entry is already bound.

To bind the entries in the list, check these entries and click the <Import> button, then the settings will

take effect if the entries do not conflict with the existed entries.

Note:

If the local hosts suffered from ARP attack, you cannot add IP-MAC Binding entries on this page.

Please add entries manually on 4.6.1.1 IP-MAC Binding.

4.6.1.3 ARP List

On this page, the IP-MAC information of the hosts which communicated with the Router recently will

be saved in the ARP list.

Choose the menu Firewall→Anti ARP Spoofing→ARP List to load the following page.
