TL-R4299G Dual-WAN SMB Broadband Router User Guide

¾ Statistics Table - This table displays the statistics information about the traffic.

IP Address

MAC Address

The IP address whose statistics information are displayed

Packets

The total amount of packets received and transmitted by the router

Total

Bytes

The total amount of bytes received and transmitted by the router

Packets

The total amount of packets received and transmitted in the last “Packets

Statistic interval” seconds

Bytes

The total amount of bytes received and transmitted in the last “Packets

Statistic interval” seconds

ICMP Tx

The total amount of the ICMP packets transmitted to WAN in the last

“Packets Statistic interval” seconds

UDP Tx

The total amount of the UDP packets transmitted to WAN in the last

“Packets Statistic interval” seconds

Current

TCP SYN

The total amount of the TCP SYN packets transmitted to WAN in the last

“Packets Statistic interval” seconds

)

Note:

1) If the Current Statistics Status function is disabled, the DoS protection in Advanced

Security will be ineffective.

2) Select the Auto-refresh, then the traffic information will be refreshed automatically

during the Packets Statistics Interval. Click the Refresh button to refresh the information

in the table immediately.

Click the Auto-refresh checkbox to refresh automatically.

Click the Refresh button to refresh immediately.

Click the Reset All button to recount again.

Click the Delete All button to delete all the number.

4.13.10 WAN Speed Detect

Choose menu “System Tools→WAN Speed Detect”, you can detect the wan speed of the router

in the screen below. There are three detecting ways: ICMP DETECT, TCP DETECT, UDP

DETECT. The detect way is the router sends datagram to destination ip address, and then counts

the interval between sending the datagram and receiving the response.
