14
Charging the battery pack (continued)
Shooting still images
In normal shooting
1)
1) Shooting at 30-second intervals with [P.
QUALITY] set to [FINE], LCD screen turned
on, flashed every two shootings and turned on/
off every ten shootings.
In continuous shooting
2)
2) Shooting at about 3-second intervals with [P.
QUALITY] set to [STANDARD] and the flash
set to (No flash).
Viewing still images
3)
3) Playing back images in order at about 3-second
intervals on the single-image screen with the
LCD screen turned on.
Shooting movies
4)
4) Continuous shooting with an image size of
160×112
• The battery life and the number of images
recordable or playable are decreased under the
following conditions:
– At low temperature.
– Using the flash.
– Turning on and off frequently.
– When [LCD BACKLIGHT] is set to
[BRIGHT]
– When [POWER SAVE] is set to [OFF].
– During Bluetooth connection
– Using the battery pack that was used
repeatedly or the battery capacity decreases
as time passed (page 105).
The POWER SAVE function
When the POWER SAVE function is
activated, you can shoot for a longer period
of time.
Set the MODE dial to SET UP, and set
[POWER SAVE] in (SETUP 1) to
[ON]. The factory setting is [ON]
(page 102).
• The [POWER SAVE] item is only shown when
using the battery pack.
When the POWER SAVE function is
activated
• The LCD screen will be darker than it is when
[POWER SAVE] is set to [OFF]. You cannot
change the settings for [LCD BACKLIGHT] at
this time (page 102).
• When shooting sill images, the focus works
only while the shutter button is pressed down
halfway.
Image size
NP-FC10 (supplied)
No. of
images
Battery life
(min.)
2272×1704
Approx. 140 Approx. 70
size
LCD
screen
NP-FC10 (supplied)
No. of
images
Battery
life (min.)
2272×1704
ON Approx. 1 400
Approx. 70
OFF Approx. 2 000
Approx. 100
640×480
ON Approx. 1 400
Approx. 70
OFF
Approx. 2 000
Approx. 100
Image size
NP-FC10 (supplied)
No. of
images
Battery life
(min.)
2272×1704
Approx. 3 200
Approx. 160
640×480
Approx. 3 200
Approx. 160
NP-FC10 (supplied)
LCD screen ON
(min.)
LCD screen OFF
(min.)
Approx. 70 min Approx. 100 min
