99
Additional information
When the MODE dial is set to (when [MOVING IMAGE] is set to [MULTI BURST] in the SET UP settings)
Item Setting Description
(EV) +2.0EV / +1.7EV / +1.3EV /
+1.0EV / +0.7EV / +0.3EV / x0EV
/ −0.3EV / −0.7EV / −1.0EV /
−1.3EV / −1.7EV / −2.0EV
Adjusts the exposure (page 47).
9 (FOCUS) ∞ / 7.0m / 3.0m / 1.0m / 0.5m /
CENTER AF / x MULTI AF
Chooses the auto focus method (page 45) or sets the focus preset distance (page 47).
WB (WHITE BAL) / / / / xAUTO Sets the white balance (page 49).
(
SPOT METER
)
ON / x OFF Matches the exposure to the subject you want to shoot (page 48).
(INTERVAL) 1/7.5 / 1/15 / x1/30 (NTSC)
1/6.3 / 1/12.5 / x1/25 (PAL)
– In NTSC mode, choose the Multi Burst between-frame shutter interval.
– In PAL mode, choose the Multi Burst between-frame shutter interval.
• The choices of between-frame shutter interval differ depending on the setting of
the [VIDEO OUT] item in the SET UP setting (page 102).
(P.QUALITY) xFINE / STANDARD Records images with fine image quality mode. / Records images in the standard
image quality mode (page 33).
PFX (P.EFFECT) SOLARIZE / B&W / SEPIA /
NEG.ART / xOFF
Sets the special effects for the image (page 55).
(SHARPNESS) +2 / +1 / x0 / –1 / –2 Adjusts the sharpness of the image. The indicator appears (except when the
setting is 0).
