96
Menu items
Menu items that can be changed differ
depending on the position of the MODE
dial. The LCD screen shows only the items
you can operate based on the current
position of the MODE dial. (When using
the Bluetooth function, see the
Bluetooth function operating
instructions.) Factory settings are
indicated with x.
When the MODE dial is set to
When the MODE dial is set to P or SCN
Item Setting Description
(IMAGE SIZE) x2272×1704 / 2272 (3:2) /
1600×1200 / 1280×960 / 640×480
Selects the image size used when shooting still images (page 21).
MODE (REC MODE) VOICE
E-MAIL
xNORMAL
– Records an audio file (with a still image) in addition to the JPEG file (page 54).
– Records a small-size (320×240) JPEG file in addition to the selected image size
(page 53).
– Records an image using the normal recording mode.
Item Setting Description
SCN x / /
/ Selects one of the Scene selections. (When the MODE dial is set to P, this setting
cannot be carried out.) (page 31)
(EV) +2.0EV / +1.7EV / +1.3EV /
+1.0EV / +0.7EV / +0.3EV / x0EV
/ −0.3EV / −0.7EV / −1.0EV /
−1.3EV / −1.7EV / −2.0EV
Adjusts the exposure (page 47).
9 (FOCUS) ∞ / 7.0m / 3.0m / 1.0m / 0.5m /
CENTER AF / x MULTI AF
Chooses the auto focus method (page 45), or sets the focus preset distance (page 47).
