Troubleshooting

For "InfoLITHIUM"

BATTERY ONLY

• The battery pack is not the “InfoLITHIUM” type.

• The battery level is low or zero. Charge the battery (page 11). Depending on the conditions of use or the type of

battery pack, the indicator may flash even though there are still 5 to 10 minutes of remaining battery time left.

• Camera shake may occur due to insufficient light. Use the flash, mount the camera on a tripod, or otherwise secure

the camera in place.

ROTATE THE LENS

PORTION

• The lens portion is falling downward. Rotate the lens portion.

Message Meaning/ Corrective Action
