13
Connecting Network Cables
The Switch supports 16 10/100Mbps Ethernet ports and Ports 1 ~ 8
are PoE Enabled ports. These PoE ports will be automatically
activated when a compatible terminal is identified. The Switch will
supply power through the Ethernet port to the connected PoE device.
For Legacy devices that are not yet compatible, the PoE port will not
offer the power to these devices. This feature allows users to freely
and safely mix legacy and Power over LAN compatible devices on
their network.
The Switch supports 10Mbps Ethernet or 100Mbps Fast Ethernet and
it runs both in half- and full- duplex mode using two pairs of Category
5 cables.
These RJ45 ports are Auto-MDI type port. The Switch can auto
transform to MDI-II or MDI-X type, so you can just make an easy
connection without worrying if you are using a standard or crossover
RJ45 cable.
AC Power
The Switch uses the AC power supply 100-240V AC, 50-60 Hz. The
power switch is located at the rear of the unit adjacent to the AC
power connector and the system fan. The Switch’s power supply will
adjust to the local power source automatically and may be turned on
without having any or all LAN segment cables connected.
