20
Discovery List
This is the list where you can discover all the Web managed devices
in the entire network.
By pressing the “Discovery” button, you can list all the Web Managed
devices in the discovery list.
Double click or press the “Add to monitor list” button to select a
device from the Discovery List to the Monitor List.
System word definitions in the Discovery List:
l MAC Address: Shows the device MAC Address.
l IP Address: Shows the current IP address of the device.
l Protocol version: Shows the version of the Utility protocol.
l Product Name: Shows the device product name.
l System Name: Shows the appointed device system name.
l Location: Shows where the device is located.
l Trap IP: Shows the IP where the Trap is to be sent.
l Subnet Mask: Shows the Subnet Mask of the device.
l Gateway: Shows the Gateway of the device.
Monitor List
All the Web Smart Devices in the Monitor List can be monitored; you
can also receive the trap and show the status of the devices.
System word definitions in the Monitor List:
