21
l S: Shows the system symbol of the Web-Smart device,
represents a device system that is not alive.
l IP Address: Shows the current IP address of the device.
l MAC Address: Shows the device MAC Address.
l Protocol version: Shows the version of the Utility protocol.
l Product Name: Shows the device product name.
l System Name: Shows the appointed device system name.
l Location: Shows where the device is located.
l Trap IP: Shows the IP where the Trap is to be sent.
l Subnet Mask: Shows the Subnet Mask set of the device.
l Gateway: Shows the Gateway set of the device.
View Trap: The Trap function can receive the events that happen on
the Web Management Switch in the Monitor List.
There is a light indicator behind the “View Trap” button. When the
light is green, it means that there is no trap transmitted, and when it is
red, it means that a new trap has been transmitted, reminding us to
view the trap. (Figure 7)
Figure 7.
When the “View Trap” button is clicked, a Trap Information window
will pop up. It will display the trap information including the Symbol,
Time, Device IP, and the Event occurred. (Figure 8)
The symbol “ ” represents the trap signal, this symbol will disappear
after you review and click on the event record.
