CONFIGURATION
Through the Web browser you can configure Switch functions such as
VLAN, Trunking, and QoS… etc.
With the attached Web Management Utility, you can easily discover
all the Web Managed Switches, assign IP Addresses, change the
passwords, and upgrade new firmware.
Installing the Web Management Utility
The following instructions guide you through the installation of the
Web Management utility.
1. Insert the Utility CD in the CD-ROM Drive.
2. From the Start menu on the Windows desktop, choose Run.
3. In the Run dialog box, type D:\Web Management
Utility\setup.exe (D:\ depends where your CD-ROM drive is
located) and click OK.
4. Follow the on-screen instructions to install the utility.
5. Upon completion, go to Program Files ->
web_management_utility and execute the Web Management
utility. (Figure 6.)
