Fluke 709 [19/20] User replaceable parts
![Fluke 709 [19/20] User replaceable parts](/views2/1435991/page19/bg13.png)
Precision Loop Calibrator
User-Replaceable Parts
15
User-Replaceable Parts
User-replaceable parts are listed in Table 3 and shown in Figure 6. For more information
about these items and their prices, contact a Fluke representative. See the Contact Fluke
section.
Table 3. User-Replaceable Parts
Item
Number
Description
Fluke Part
Number
709 Case Assembly (includes case top and bottom with labels,
battery door, end plate with jacks)
4341550
709H/710* Case Assembly (includes case top and bottom with
labels, Lemo, battery door, end plate with jacks)
*710 Case requires additional labels, 4991114 and 4996903
4341561
Not Shown Fluke-710, Battery Door Label (use with 709H case) 4991114
Not Shown Fluke-710, Display Lens Label (use with 709H case) 4996903
Fluke-709-2005, Knob 4282155
Fluke-709-2006, Holster, Fluke-709 4241437
Fluke-709H-2006, Holster, Fluke-709H/Fluke-710 4241443
Fluke-709-2007, Bail, Fluke709/709H/Fluke-710 4241455
Not Shown Gasket, Black, Fluke 709 Remote 4440367
Not Shown Fluke-709-8003, Keypad, Fluke-709/709H/Fluke-710 4252551
Not Shown TL75-4201, Test Leads 855742
Not Shown AC280 Suregrip Hook Clip (black) 2063165
Not Shown AC280 Suregrip Hook Clip (red) 1613782
Not Shown TP220 Test Probes (red) 2047206
Not Shown TP220 Test Probes (black) 2063129
Not Shown Alligator Clip Set, Extended Tooth 3765923
Not Shown Stackable Lead Set 3669716
Not Shown USB to 5-Pin Cable, 6-ft 4401616
Not Shown 710 ValveTrack Software-available as a free download at www.fluke.com.
Not Shown 709H/TRACK Datalogging Software & Cable 4281225
Not Shown Softcase 2643273
Not Shown Screw, Pan, Phillips, Thread Forming, #3 Head 642931
