![Fluke 714B [18/50] Required equipment](/views2/1437103/page18/bg12.png)
712B/714B
Calibration Manual
10
Required Equipment
The equipment listed in Table 2 is necessary to do the calibration and test for the
712B. The equipment listed in Table 3 is necessary to do the calibration and test
for the 714B.
Note
Fluke 5522A and Fluke 8508A need an 8-hour warmup period
before the calibration starts. The 5522A needs to zero all the
functions weekly and zero Ohms output function every day. The
8508A needs to zero the dc V measurement function, the 4-Wire
Ohms measurement function and the DCI measurement function.
Table 2. Required Equipment for 712B Verification and Calibration Adjustment
Item Equipment QTY Comment
Fluke 5522A 1 ——
Fluke 8508A 1
Can be replaced with other
reference or equivalent
DMMs
B-36-2,BANANA PLUG
PATCH CORD (Part
number:1894785, RED, Part
number: 1894724, BLACK)
Or
Fluke-75X-8014,
STACKABLE LEAD SET
(Part number: 3669716)
2 sets
Used for all the function
calibration and verification
test
Table 3. Required Equipment for 714B Verification and Calibration Adjustment
Item Equipment QTY Comment
Fluke 5522A 1 The mV output should be calibrated by 8508A
[1]
.
Fluke 8508A 1
Can be replaced with other reference or
equivalent DMMs
[2]
.
Fluke 9101-256 1
Can be replaced with a lag bath and standard
sensors
[3]
Pure copper cables
with the mini plug
1
Used for the calibration of the mV input function
and mV source function
J TYPE and K TYPE
TC Sensor
[4]
1
Used for verification and calibration adjustment
of the temperature function
Fluke-75X-8014 1 Fluke Item No: 3669716
Fluke 7526A 1 -
[1] Before using the mV output function of 5522A, record the 5522A output setting by the reading of the
8508A.
[2] The absolute uncertainties of the DMM’s dc voltage need to be better than 10 ppm+0.2 μV in the range of
0 mV and 100 mV.
[3] The accuracy (MAX) of standard sensors should be better than 0.05 °C.
[4] The accuracy (MAX) of the TC sensor should be better than 0.05 °C.
