LEDS
3
.
W
ess Basics
M2 LED -
A solid light indicates that
the unit is defective.
M1 LED -
A
solid light
indicates that the
DI-614+ is ready.
WAN LED -
A
solid light
indicates
connection on the
WAN port. This
LED blinks during
data transmission.
POWER LED -
A
solid light
indicates a proper
connection to the
power supply.
WLAN LED -
A
solid light
indicates that the
wireless segment
is ready. This
LED blinks
during wireless
data
transmission.
LOCAL
NETWORK LED -
A
solid light
indicates a
connection to an
Ethernet-enabled
computer on ports
1-4. This LED
blinks during data
transmission.
A solid light indicates
that the unit is defective.
DI-624 is ready.
