TL-MR3040 Portable Battery Powered 3G/4G Wireless N Router
-99-
¾ Packets Statistics Interval （5-60） - The default value is 10. Select a value between 5
and 60 seconds in the pull-down list. The Packets Statistic interval indicates the time
section of the packets statistic.
¾ Sorted Rules - Choose how displayed statistics are sorted.
Select the Auto-refresh checkbox to refresh automatically.
Click the Refresh button to refresh immediately.
Click Reset All to reset the values of all the entries to zero.
Click Delete All to delete all entries in the table.
Statistics Table:
IP/MAC Address
The IP and MAC address are displayed with related statistics.
Packets
The total number of packets received and transmitted by the
router.
Total
Bytes
The total number of bytes received and transmitted by the router.
Packets
The total number of packets received and transmitted in the last
Packets Statistic interval seconds.
Bytes
The total number of bytes received and transmitted in the last
Packets Statistic interval seconds.
ICMP
Tx
The number of the ICMP packets transmitted to WAN per second
at the specified Packets Statistics interval. It is shown like
“current transmitting rate / Max transmitting rate”.
UDP Tx
The number of UDP packets transmitted to the WAN per second
at the specified Packets Statistics interval. It is shown like
“current transmitting rate / Max transmitting rate”.
Current
TCP
SYN Tx
The number of TCP SYN packets transmitted to the WAN per
second at the specified Packets Statistics interval. It is shown like
“current transmitting rate / Max transmitting rate”.
Reset
Reset the value of he entry to zero.
Modify
Delete
Delete the existing entry in the table.
There would be 5 entries on each page. Click Previous to return to the previous page and Next
to the next page.
