Tp-Link TL-MR3040 [21/241] Router configuration

TL-MR3040 Portable Battery Powered 3G/4G Wireless N Router

-10-

3. When Connected appears, you’ve successfully connected to the wireless network.

3.2.2 Router Configuration

To access the configuration utility, open a web-browser and type the default address

http://192.168.0.1 in the address field of the browser.

Figure 3-1 Login the Router

After a moment, a login window will appear, similar to the Figure 3-2. Enter admin for t

he User

Name and Password, both in lower case letters. Then click the OK button or press the Enter

key.

Figure 3-2 Login Windows

)

Note:

If the above screen does not pop-up, it means that your Web-browser has been set to a proxy.

Go to Tools menu>Internet Options>Connections>LAN Settings, in the screen that appears,

cancel the Using Proxy checkbox, and click OK to finish it.

There are three Operation Modes: 3G/4G Router Mode, WISP Client Mode and Travel Router

(AP) Mode. The Operation Modes can only be switched by the Mode Switch button in one side

of the router.

1. 3G/4G Router Mode

1. Switch the mode to 3G/4G Router Mode. Login the management page again. You can

click the Quick Setup menu to quickly configure your router, and then click Next. Here we

take 3G/4G Only for example.
