TL-MR3040 Portable Battery Powered 3G/4G Wireless N Router

-130-

time is up, the user will be automatically assigned a new dynamic IP address. The range

of the time is 1 ~ 2880 minutes. The default value is 120 minutes.

¾ Default Gateway - (Optional) Suggest to input the IP address of the LAN port of the router,

default value is 192.168.0.1.

¾ Default Domain - (Optional) Input the domain name of your network.

¾ Primary DNS - (Optional) Input the DNS IP address provided by your ISP. Or consult your

ISP.

¾ Secondary DNS - (Optional) Input the IP address of another DNS server if your ISP

provides two DNS servers.

) Note:

To use the DHCP server function of the router, you must configure all computers on the LAN as

"Obtain an IP address automatically" mode.

5.7.2 DHCP Clients List

Choose menu “DHCP→DHCP Clients List”, and then you can view the information about the

clients attached to the router in the next screen (shown in Figure 5-30

Figure 5-30 DHCP Clients List

¾ ID - The index of the DHCP Client.

¾ Client Name - The name of the DHCP client.

¾ MAC Address - The MAC address of the DHCP client.

¾ Assigned IP - The IP address that the router has allocated to the DHCP client.

¾ Lease Time - The time of the DHCP client leased. After the dynamic IP address has

expired, a new dynamic IP address will be automatically assigned to the user.

You cannot change any of the values on this page. To update this page and to show the

current attached devices, click the Refresh button.

5.7.3 Address Reservation

Choose menu “DHCP→Address Reservation”, and then you can view and add a reserved

address for clients via the next screen (shown in Figure 5-31). When you specify a reserved IP

address for

a PC on the LAN, that PC will always receive the same IP address each time when
