D-Link DVA-G3340S [24/78] Accounts
![D-Link DVA-G3340S [24/78] Accounts](/views2/1045263/page24/bg18.png)
The ATM settings in the
WAN configuration
menus for the different
connection types can
be used to adjust QoS
parameters for ADSL
clients. This
may not be
available to all ADSL
accounts.
Ask your
ISP if ATM Traffic
Shaping is available for
your account.
ATM Traffic Shaping
Home > WAN
ATM VC Settings in WAN connection menu
The table below describes the ATM VC settings used to configure a connection for an
ADSL account.
ATM VC Parameters Description
PVC
The Router supports using up to eight multiple virtual
connections. This menu allows the user to configure
WAN settings for all the available connections (see
instructions below on how to set up Multiple Virtual
Connections). Use the PVC menu to select the
connection (Pvc0 to Pvc7) you want to configure.
Since most users will use only a single connection,
the default setting Pvc0 can be used for any changes
made to the WAN settings.
VPI
The Virtual Path Identifier is used with the VCI to
define a dedicated circuit on the ATM network portion
of the connection to the Internet and WAN. Most
users will not need to change this setting.
VCI
The Virtual Channel Identifier is used with the VPI to
define a dedicated circuit on the ATM network portion
of the connection to the Internet and WAN. Most
users will not need to change this setting.
Virtual Circuit
As with the PVC setting, this is mainly for use by
clients who are configuring the Router for multiple
virtual connections. Use this to enable or disable the
PVC you are currently configuring. By default, the
Pvc0 is enabled and the remaining PVCs are
