D-Link DVA-G3340S [71/78] Technical specifications

Technical Specifications

Key Component Description

Network Processor and ADSL

Chipset

TI AR7VWi

Voice Chipset TI TNETV901

Product Feature Description

Network Interface

One ADSL port RJ-11, inner pair (pin 2,3)

ADSL Standards:

ANSI T1.413 Issue 2

ITU G.992.1 (G.dmt) AnnexA

ITU G.992.2 (G.lite) Annex A

ITU G.994.1 (G.hs)

ADSL2 Standards:

ITU G.992.3 (G.dmt.bis) Annex A

ITU G.992.4 (G.lite.bis) Annex A

Standard Compliance

ADSL2+ Standards:

ITU G.992.5 Annex A

Downstream: up to 24Mbps Line Rate

Upstream : up to 1Mbps

Performance Pass DSL Forum TR-067 Performance

Criteria

LAN Interface

Four Fast Ethernet ports RJ-45, 10/100Mbps, MDI/MDIX

Auto-sesnsing

Standard Compliance IEEE802.3, IEEEE802.3u

USB Interface

One USB port Type B connector

Standard Compliance USB Implementation Forum USB 1.1

Specification

Voice Interface

RJ-11, FXS interface Two ports for POTS connection

Loop Start

One port for PSTN connection RJ-11, FXO interface

Telephone dialing mode support DTMF
