D-Link DVA-G3340S [16/78] Additional settings for dynamic ip address connections

4. Some ISPs record the unique MAC address of your computer’s Ethernet adapter

when you first access their network. This can prevent the Router (which has a

different MAC address) from being allowed access to the ISPs network (and the

Internet). To clone the MAC address of your computer’s Ethernet adapter, type in

the MAC address in the Cloned MAC Address field and click the Clone MAC

Address button.

5. Leave the MTU value at the default setting (default = 1400) unless you have

specific reasons to change this (see table below).

6. NAT should remain enabled. If you disable NAT, you not be able to use more

than one computer for Internet connections. NAT is enabled and disabled

system-wide, therefore if you are using multiple virtual connections, NAT will

disabled on all connections.

7. The Firewall should remain enabled for most users. If you choose to disable this

you will not be able to use the features configured in the Firewall and Filters

menus located in the Advanced directory. See the next chapter for more details

on these menus.

8. Most users will not need to change ATM settings. If this is the first time you are

setting up the ADSL connection it is recommended that you leave the Service

Category settings at the default values until you have established the connection.

See the table on page 22 for a description of the parameters available for ATM

traffic shaping.

9. When you are satisfied that all the WAN settings are configured correctly, click on

the Apply button.

10. The new settings must be saved and the Router must be restarted for the settings

to go into effect. To Save & Reboot the Router, click on the Tools directory tab

and then click the Save & Reboot menu button. In the Save and Reboot menu,

click the Reboot button under Force the DVA-G3340S to system restart. The

Router will save the new settings and restart. Upon restarting the Router will

automatically establish the WAN connection.

Additional settings for Dynamic IP Address connections:

Dynamic IP Parameters Description

Connection Type

This specifies the connection type and encapsulation

method used for your Dynamic IP Address connection.

The options available are Bridged IP LLC or Bridged IP

VC-MUX.

Cloned MAC Address

This is not always necessary, but may be required for

some ISPs. Type in the MAC address of your

computer’s Ethernet adapter in the Cloned MAC

Address field and click the Clone MAC Address

button. This will copy the information to a file used by

the Router to present to the ISP’s server used for

DHCP. Some ISPs record the unique MAC address of
