To modify virtual server settings for any previously created rule, click on the note pad
icon in the right hand column of the list for the set you want to configure. The
parameters that have been configured for the rule appear in the settings fields above
the list. Adjust the settings as desired and click the Apply button to put them into effect.
To delete a rule from the list, click on the trash can icon and confirm that you want to
delete the rule in the pop-up dialog box that appears.
The table below describes the configuration settings presented in the Virtual Server
menu.
To configure a virtual server set, define the following settings in the Virtual Server
configuration menu located in the top half of the browser window.
Parameter Description
Rule Name
Provide a name for the rule. This name will not
appear in the list below, however it may be useful if
you later need to edit the settings for the rule. Rule
names are optional.
Private IP
This is the IP address of the server on your LAN that
will provide the service to remote users. The Private
IP address is used to direct the service to a specific
computer on your private network such as an FTP,
Email or public web server. Type in the IP address of
the server used for the service being configured
here.
Protocol
You can select the transport protocol (TCP or UDP)
that the application on the virtual server will use for
its connections. Select one of the following options
from the pull-down menu to define a TCP, UDP or
Both. The choice of this protocol is dependent on the
application that is providing the service. If you do
not know which protocol to choose, check your
application’s documentation.
Port Start /Port End
Configure a range of ports for forwarding. Type the
lowest numbered port in the range in the Port Start
space. Type the highest numbered port in the Port
End space. For a single port, just enter the same
number in both spaces.
Virtual server port redirection must be used with a
specified server or computer on the LAN (identified
by the Private IP address).
