The parameters described below are used to set up filter rules.

Parameter Description

Source IP

For an Outbound Filter, this is the IP address or IP addresses

on your LAN for which you are creating the filter rule. For an

Inbound Filter, this is the IP address or IP addresses for which

you are creating the filter rule. You can opt to indicate a Mask

Range, a Single IP, an IP Range or Any IP from the pull-down

menu. Choosing Any IP will apply the rule to all WAN or all LAN

IP addresses depending on which type of rule (Inbound or

Outbound) is being configured.

Destination IP

Where the Destination IP address resides also depends on if

you are configuring an Inbound or Outbound filter rule. You can

opt to indicate a Mask Range, a Single IP, an IP Range or Any

IP from the pull-down menu.

Source Port

The Source Port is the TCP/UDP port on either the LAN or

WAN depending on if you are configuring an Outbound or

Inbound Filter rule. Select one of the following options from the

pull-down menu to define a Any Port, Single Port, Port Range

or Safe Range (ports above 1024).

Destination Port

The Destination Port is the TCP/UDP port on either the LAN or

WAN depending on if you are configuring an Outbound or

Inbound Filter rule. Select one of the following options from the

pull-down menu to define a Any Port, Single Port, Port Range

or Safe Range (ports above 1024).

Protocol

Select the transport protocol (TCP, UDP or All) that will be used

for the filter rule.

Action

Select to Allow or Deny transport of the data packets

according to the criteria defined in the rule. Packets that are

allowed are routed to their destination; packets that are denied

are blocked.

Click the Apply button to put the new rule into effect. Any filter rule configured in the

menu will appear in the Filters List with the new settings. The Router must save the new

settings and reboot before the new rules are applied.
