Gigabyte GA-M52LT-D3P (rev.3.0) [10/88] 2 product specifications
![Gigabyte GA-M52LT-D3P (rev.3.0) [10/88] 2 product specifications](/views2/1045384/page10/bga.png)
Hardware Installation - 10 -
1-2 Product Specications
CPU AM3+ Socket:
- AMD AM3+ FX processor
- AMD Phenom
™
II processor/ AMD Athlon
™
II processor
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper Transport
Bus
2000 MT/s
Chipset NVIDIA
®
nForce 520LE
Memory 4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
* Due to Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than 4 GB.
Dual channel memory architecture
Support for DDR3 1600/1333/1066/800 MHz memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Audio Realtek ALC889/892 codec
High Denition Audio
2/4/5.1/7.1-channel
Support for S/PDIF In/Out
Support for CD In
LAN Realtek RTL8201EL chip (10/100 Mbit)
Expansion Slots 1 x PCI Express x16 slot, running at x16
2 x PCI Express x1 slots
4 x PCI slots
Storage Interface Chipset:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE
devices
- 2 x SATA 3Gb/s connectors supporting up to 2 SATA 3Gb/s devices
- Support for RAID 0 and RAID 1
iTE IT8720 chip:
- 1 x oppy disk drive connector supporting up to 1 oppy disk drive
USB Chipset:
- Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
1 x oppy disk drive connector
1 x IDE connector
2 x SATA 3Gb/s connectors
1 x CPU fan header
1 x system fan header
1 x power fan header
1 x front panel header
1 x front panel audio header
1 x CD In connector
