Appendix - 68 -
Step 6:
After assigning the RAID drives, press <F7>. A message which says "Clear disk data?" appears (Figure 6).
Press <Y> to conrm or press <N> to cancel. (If the hard drives contain a previously created RAID array, you
need to press <Y> to clear the data in the hard drives.)
Figure 5
Figure 6
Step 5:
Next, select the hard drives which you wish to be included in the disk array. The Free Disks block displays
the information about the SATA hard drives that are available for use as RAID array drives. Press <Tab> to
move to the Free Disks block. Select the target hard drives using the up or down arrow key and use the right
arrow key to add the hard drives to the Array Disks block (Figure 5).
MediaShield Utility Nov 20 2006
-DeneaNewArray-
[ESC] Quit [F6] Back [F7] Finish [TAB] Navigate [
hi
] Select [ENTER] Popup
[
] Add
[
] Del
Array Disks
Port Disk Model Capacity
RAID Mode : Striping
Striping Block: Optimal
Free Disks
Port Disk Model Capacity
1.0 ST3120026AS 111.79GB
1.1 ST3120026AS 111.79GB
MediaShield Utility Nov 20 2006
-DeneaNewArray-
[ESC] Quit [F6] Back [F7] Finish [TAB] Navigate [
hi
] Select [ENTER] Popup
[
] Add
[
] Del
Array Disk
Port Disk Model Capacity
RAID Mode : Striping
Striping Block: Optimal
Free Disks
Port Disk Model Capacity
1.0 ST3120026AS 111.79GB
1.1 ST3120026AS 111.79GB
Clear disk data?
[Y] YES [N] NO
