- 69 - Appendix
After that, the Array List screen appears, displaying the RAID array that you have created (Figure 7).
MediaShield Utility Nov 20 2006
- Array List-
[Ctrl-X] Exit [
hi
] Select [B] Set Boot [N] New Array [ENTER] Detail
Boot Status Vender Array Model Name
No Healthy NVIDIA STRIPE 223.57G
To read more information about the RAID array, press <Enter> to enter the Array Detail screen (Figure 8),
which shows various information about the array, including the RAID mode, stripe block size, hard drive
model name, and hard drive capacity, etc.
To delete the array, press <D> in the Array Detail screen. When the "Delete this array?" message appears,
press <Y> to conrm or <N> to cancel. Press <Enter> to return to the Array List screen.
To exit the NVIDIA RAID setup utility, press <Esc> in the main menu or <Ctrl>+<X> in the Array List screen.
Now, you can proceed to the installation of the SATA controller driver and operating system.
MediaShield Utility Nov 20 2006
- Array Details-
RAID Mode: Striping
Striping Width : 2 Striping Block: 64K
Port Index Disk Model Capacity
1.0 0 ST3120026AS 111.79GB
1.1 1 ST3120026AS 111.79GB
[R] Rebuild [D] Delete [C] Clear Disk [ENTER] Return
Figure 7
Figure 8
