Appendix - 66 -
B. Conguring SATA controller mode in BIOS Setup
Make sure to congure the SATA controller mode correctly in system BIOS Setup.
Step 1:
Turn on your computer and press <Delete> to enter BIOS Setup during the POST (Power-On Self-Test). Un-
der Integrated Peripherals, make sure NV SATA Controller is enabled. To enable RAID, go to the Serial-
ATA RAID Cong (Figure 1).
Step 2:
Save changes and exit BIOS Setup.
Figure 1
The BIOS Setup menus described in this section may differ from the exact settings for your moth-
erboard. The actual BIOS Setup menu options you will see shall depend on the motherboard you
have and the BIOS version.
Set NV SATA RAID function to Enabled to enable RAID control for each SATA connector. Then set NV
SATA 1 Primary RAID and NV SATA 1 Secondary RAID to Enabled. (Figure 2).
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Serial-ATARAIDCong
NV SATA RAID function [Enabled]
NV SATA 1 Primary RAID [Enabled]
NV SATA 1 Secondary RAID [Enabled]
hi
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
Figure 2
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Integrated Peripherals
On-Chip IDE Channel [Enabled]
NV SATA Controller [Enabled]
IDE Prefetch Mode [Enabled]
Serial-ATARAIDCong [PressEnter]
Onboard Audio Function [Auto]
On-Chip MAC Lan [Auto]
Onboard LAN Boot ROM [Disabled]
Onboard Serial Port 1 [3F8/IRQ4]
Onboard Parallel Port [378/IRQ7]
Parallel Port Mode [SPP]
x ECP Mode Use DMA 3
USB Controllers [Enabled]
USB Legacy Function [Enabled]
USB Storage Function [Enabled]
hi
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
