Storing and recalling stations
You can easily store up to six stations for each
band as presets.
1 Display the preset screen.
Refer to Introduction of tuner operations on
page 15.
The preset screen appears in the display.
2 Touch and hold one of the preset tun-
ing keys to store the selected frequency in
the memory.
The selected radio station frequency has been
stored in the memory.
3 Touch one of the preset tuning keys to
select the desired station.
Displaying radio text
Radio text data transmitted by RDS stations,
such as station information, the name of the
currently broadcast song and the name of the
artist, can be displayed on this tuner.
! When no radio text is received, No Text ap-
pears in the display.
Storing and recalling radio
text
You can store data from up to six radio text
transmissions to the Memo1 to Memo6 keys.
1 Display the radio text you want to
store in the memory.
Refer to Introduction of tuner operations on
page 15.
2 Touch and hold one of the keys to store
the selected radio text.
The memory number is displayed and the se-
lected radio text will be stored in the memory.
The next time you press the same key in radio
text display the stored text will be recalled
from the memory.
Storing the strongest stations
BSM (best stations memory) automatically
stores the six strongest stations in the order of
their signal strength.
Storing broadcast frequencies with BSM may
replace broadcast frequencies you have saved
using the preset tuning keys.
1 Display the preset screen.
Refer to Introduction of tuner operations on
page 15.
The preset screen appears in the display.
2 Touch BSM/BSSM to turn BSM on.
The six strongest broadcast frequencies will
be stored under preset tuning keys in order of
their signal strength.
# To cancel the storage process, touch
Cancel.
Tuning in to strong signals
Local seek tuning lets you tune in to only
those radio stations with sufficiently strong
signals for good reception.
FM: Off —
— — —
MW/LW: Off — —
The highest level setting allows reception of
only the strongest stations, while lower levels
allow the reception of weaker stations.
Using iTunes tagging
This function can be operated with the following
iPod models.
— iPod touch 4th generation
— iPod touch 3rd generation
— iPod touch 2nd generation
— iPod touch 1st generation
— iPod classic 160GB
— iPod classic 120GB
— iPod classic
— iPod with video
En
30
Section
12
Detailed instructions
