KTS functions
at a glance
KTS functions KTS 800 KTS 670 KTS 570 KTS 540 KTS 530 KTS 515 KTS Truck KTS 340 KTS 200
Truck
Diagnostics programs, passenger cars – ✔ ✔
✔ ✔ – ✔ ✔ ✔
- ISO systems for EU vehicles
- ISO 9141-2, K
/
L lines, blink code
- SAE systems for American and
Japanese vehicles
- SAE J 1850 VPW (Ford)
corresponds to ISO 11 519-4
- SAE J 1850 PWM (GM,...)
corresponds to ISO 11 519-4
- OBD CAN protocols
- CAN ISO 11898 ISO 15765-4 OBD
- High-speed
- High-speed, middle-speed,
Low-speed and single-wire CAN
Diagnostics programs for commercial vehicles ✔ – – – – – ✔ – –
- SAE J 1939
Mobile communications connection to the PC ✔ – ✔ ✔ ✔ ✔ ✔ ✔
–
- Bluetooth ✔ – ✔ ✔ ✔ ✔ ✔ –
–
- WLAN ✔ – – – – – – ✔
–
USB interface ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔
AWN capability ✔ ✔ ✔ ✔ ✔ –
– – –
Integration into company-internal networks ✔ ✔ – – – –
– – –
Measuring techniques – ✔ ✔ ✔
✔
✔
– – –
Accuracy: 1% of measured value
Voltage: Min. resolution 0.1 mV;
max. measurement range 200 V
Resistance: Min. resolution 100 mOhm;
max. measurement range 1mOhm
Current: Min. resolution 0.1 mA;
max. measurement range 1000 A
(special accessory)
- 1-channel multimeter –
–
– ✔ ✔
–
– – –
- 2-channel multimeter – ✔ ✔
–
–
– – ✔ –
- 2-channel oscilloscope – ✔ ✔
– –
–
– – –
Input resistance: 1 mOhm
Trigger: Various sources
Memory: 50 signal curve each with 2 channels
Channel 1: No voltage
Channel 2: No voltage
1-channel operation: 10 megasamples / sec
2-channel operation: 2x5 megasamples / sec
Display 13.3" 12.1" – – – – – 8.4" 3.5"
Operation ✔ ✔
–
–
–
–
–
✔ ✔
- Touchscreen ✔ ✔
–
–
–
–
–
✔ –
- Buttons ✔ ✔
–
–
–
–
–
✔ ✔
OBD-exchange adapter, controlled by software
ESI[tronic]
- Interchangeable – ✔ ✔ ✔ ✔ ✔ – ✔ –
- Multiplex system – ✔ ✔ ✔ ✔ ✔ – ✔ ✔
Model Order number Model Order number Model Order number
KTS 800 Truck 0 684 400 800 KTS 540 0 684 400 540 KTS Truck 0 684 400 512
KTS 670 0 684 400 670 KTS 530 0 684 400 530 KTS 340 0 684 400 340
KTS 570 0 684 400 570 KTS 515 0 684 400 515 KTS 200 0 684 400 200
