KTS functions
at a glance
KTS 800
1
KTS 670
1
KTS 570
1
KTS 540
1
KTS 530
1
KTS 515
1
KTS Truck
1
KTS 340
1
KTS 200
1
Truck
KTS functions
Connection option
- DVD drive ✔ ✔ – – – –
– – –
- Keyboard / mouse ✔ ✔ – – – –
– – –
- Printer connection ✔ ✔ – – – – – ✔ –
Equipment in line with workshop needs
- Effective impact protection ✔ ✔ – – – –
– ✔ ✔
- Splash protected ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔
- Functional temperature range 0 to 40 °C ✔
✔
✔ ✔ ✔
✔
✔ ✔ ✔
Power supply
- Via vehicle battery (diagnostic plug) – ✔ ✔
✔
✔
✔ – ✔ ✔
- Via internal battery ✔ ✔ – – – – – ✔ –
- Via cigarette lighter ✔ ✔
✔
✔
✔
✔ ✔ ✔ ✔
- Via mains adapter ✔ ✔
✔
✔
✔
✔ – ✔ ✔
Adapter concept "Easy Connect" – ✔ ✔ ✔ ✔ – – – ✔
Possible ESI[tronic] information
- Catalog and parts information ✔ ✔ ✔ ✔ ✔ – ✔ – –
- Order processing and calculation ✔ ✔ – – – – – – –
- Diagnostics and repair at the vehicle ✔ ✔ ✔ ✔ ✔ – ✔ ✔ –
- Diagnostics and repair at the product ✔ ✔ ✔ ✔ ✔ – – – –
- Diagnostics ✔ ✔ ✔ ✔ ✔ – ✔ ✔ ✔
- OBD diagnostics
✔
3
✔ ✔ ✔ ✔ ✔
✔
3
✔ ✔
Equipment supply
Mains adapter (15 V / 1 A) – – ✔
✔ ✔ ✔ – – ✔
Mains adapter (15 V / 4 A) – ✔ – – – – – ✔ –
Mains adapter (20 V / 3.5 A) ✔ – – – – – – – –
Mains connection cable ✔ ✔ ✔ ✔ ✔ ✔ – ✔ ✔
OBD exchange adapter, interchangeable ✔ ✔ ✔ ✔ – ✔ –
OBD diagnosis cable 1.5 m ✔
2
– ✔
✔ – ✔ ✔
2
– ✔
OBD diagnosis cable 3.0 m ✔ – – ✔
–
✔ –
Uni-4 adapter – ✔ ✔ ✔ ✔ – – ✔ –
Universal adapter set ✔ – – – – – ✔ – –
Measurement cable, 2-wire (red, black) 3 m – ✔ ✔
– – – – – –
Measurement cable, 2-wire (blue, yellow) 3 m – ✔ ✔
– – – – – –
Measurement cable, blue / yellow – – – ✔ ✔ – – ✔ –
Measurement cable, black – ✔ ✔ ✔ ✔ – – ✔ –
Test probe, red – 2x 2x ✔ ✔ – – 2x –
Connection terminal, black – ✔ ✔ ✔ ✔ – – ✔ –
DVD drive ✔ ✔ –
– – – – – –
USB connecting line 1 m ✔ ✔ – – – ✔ ✔ – ✔
USB connecting line 3 m – – ✔
✔ ✔ – – ✔ –
Bluetooth USB adapter ✔ – ✔
✔ – ✔ ✔ – –
Touchpen ✔ ✔ – – – – – ✔ –
Carrying case ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔
Mounting (KTS 530 / 540 / 570) – – ✔
✔ ✔ – – – –
8x battery AA cells for KTS 340 – – –
– – – – ✔ –
2x lithium-ion batteries for DCU 130 ✔ – – – – – – – –
1
Device only operative with ESI[tronic] enabling / licensing
2
OBD diagnosis cable Truck 0.9 m
3
In preparation
