Bosch KTS 540 [9/28] Kts 570 540 wi l ss and kts 530 diagnostics experts for the latest technology

9

Oscilloscope measurement parallel to diagnosis

KTS 570 / 540 wireless and KTS 530:

Diagnostics experts for the latest technology

KTS 570 / 540 wireless: Convenient and mobile

thanks to wireless Bluetooth data transfer

Ñ Bluetooth Standard Class 1 with a range of up to 100 m

Ñ Bluetooth USB adapter from Bosch included in scope of

KTS 530 without radio module, otherwise same functions

as KTS 540

Data exchange by radio: From KTS 570/540 wireless to PCKTS 540 wireless: Mobile workshop deployment for fast workflows

Simplified adapter concept “Easy Connect”

For reliable recognition of manufacturer-specific

diagnostic connections, Bosch now introduces the new

simplified adapter concept “Easy Connect”. Now, all that

needs to be done for reliable control unit diagnostics is

to join the manufacturer-specific adapter cable and the

OBD diagnostics cable to make a direct connection.

KTS 570 / 540 / 530

Ñ Operating system supported: MS Windows XP, Vista

Home Premium, Vista Business, Windows 7 32 bit

Ñ The USB interface means that the KTS 570, KTS 540

Equipment KTS 570: 2-channel multimeter and oscillo-

scope KTS 540, 530: 1-channel multimeter

Weight approx 500 g

Connections OBD diagnostics cable, USB, mains adapter,

operation display

Wireless connection Bluetooth

Mobile communications connection fully in view

Ñ During installation and operation, the status of the

wireless connection is constantly indicated in the task

bar on the screen
