Cyberpower CPS7500PRO [10/20] General mode
![Cyberpower CPS7500PRO [10/20] General mode](/views2/1472184/page10/bga.png)
CPS7500PIE/CPS7500PRO
Copyright © 2014 CyberPower Systems, Inc.
9
9. BATTERY CAPACITY Meter: This meter displays the approximate charge level (in 20% increments) of
the EPS's external battery. During a blackout or severe brownout, the EPS will switch to battery power,
the ON BAT icon will be illuminated, and the charge level will decrease.
10. LOAD CAPACITY Meter: This meter displays the approximate output load level (in 20% increments)
of the EPS's battery outlets.
EPS Status Inquiry and Functions Setup
EPS status inquiry and functions setup
1. General Mode
a. Press the LCD Display Toggle (Selected Switch) to check the status of the EPS.
Item
Unit
Input Voltage
V
Output Voltage
V
Output Frequency
Hz
Load
Kw
Load Capacity
%
Battery Capacity
%
Centigrade
℃
Fahrenheit
℉
b. Press and hold the Display Toggle for 4 seconds.
– If the machine is in the Battery Mode, it enters/leaves Silent Mode.
– If the machine is in the Line Mode, it proceeds to Self Test.
c. If the Display Toggle remains untouched for over 30 seconds, the LCD backlight will turn off
automatically.
2. Set-up Mode
Step 1: The machine enters Set-up Mode after the Display Toggle is pressed and held for 10 seconds.
When icons 3, 4, 5, 6, 7, 8 (see page 8) all illuminate, the EPS is in the Set-up mode.
Step 2: By pressing the Display Toggle, users can switch setup functions:
Items
Unit
Delay Time
Min
Battery Capacity
H
Charging Current
A
Nominal Output Voltage
V
Static Frequency Tolerance
%
Slew Rate
%
Battery Shutdown Voltage
V
Mode Select
None
Firmware Version
None
Last Shutdown Event
None
