CPS7500PIE /CPS7500PRO

a. Delay Time: The time delays for switching from Battery Mode to Line Mode. The machine will

switch from Battery Mode to Line Mode within the preset delay time after the AC power

transmission reaches stability.

Default 0.0 minutes

Choice 0.0, 0.5, 1.0, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0 minutes

b. Battery Capacity: The function adjusts the battery capacity of the used batteries.

Default 100AH

Choice 50, 75, 100, 150, 200AH, others (0H)

Note: The default value would be 100AH unless the capacity of the EPS bundling battery is not 100AH. In this

case, the default value changes according to the capacity of the bundling battery. For more information, please

see page 11 BATTERY CHARGING SETTING ARRANGEMENT.

c. Charging Current: The function adjusts the current for battery charging.

Default Medium level

Choice Lowest, Low, Medium, High level

Note: Check the setting of battery capacity before setting the charging current as the default value varies

according to the battery capacity. For more details, please see page 11 BATTERY CHARGING SETTING

ARRANGEMENT.

d. Nominal Output Voltage: AVR Dynamic Voltage Compensation works automatically based on

the system voltage settings. Please configure the correct electricity/voltage supplied in the

area/country where the EPS will be used.

Default 220V

Choice 220, 230, 240V

e. Static Frequency Tolerance: The settings may be adjusted to the quality of the electricity in use.

Default +/-10%

Choice 1, 2, 4, 6, 8, 10%

f. Slew Rate (Dynamic Frequency Tolerance): Slew Rate indicates the tolerance of a device in

accepting frequency variances. The lower Slew Rate results in less tolerance but better

protection for the connected loads.

Default 4 Hz/sec

Choice 0.25, 0.5, 1, 2, 4 Hz/Sec

g. Battery Shutdown Voltage: This function adjusts the EPS shutdown point according to the

battery voltage.

Default 44V

Choice 38, 40, 42, 44V

Note: In order to extend the lifespan of the battery, the function is applicable only when load ≥ 75%.

h. Mode Select: Using the generators as ESP input is suggested to select the Robust Mode (1);

using the computers as EPS output is suggested to select the Standard Mode (2).

Default Robust (1)

Choice Robust (1), Standard (2)
