CPS7500PIE/CPS7500PRO

7. Charger Circuit Breaker

Limit input charger current to prevent charger damaged due to overload.

8. Battery Input Wiring Fault LED

Battery input wiring fault LED will illuminate and make an audible alarm to indicate the wiring polarity is

reversed only when the DC circuit breaker is off.

*Note: Please make sure the DC circuit breaker is off before connecting the battery to the machine.

9. Output Selector

For PRO Series, the Output Selector provides four most common operation situations for switch, including

Normal, Bypass with AVR, Bypass and Off. No matter under what situations, the charger would keep

charging external batteries if utility power is still alive.

Normal: The unit will provide all functions of uninterruptible power supply include charger.

Bypass with AVR: The unit will bypass the utility power with voltage regulator and shutdown the unit when the utility

power exceeds 300Vac or below 140Vac.

Bypass: The unit will bypass the utility power to output directly.

*Note: Bypass model wouldn’t provide any overvoltage protection .Utility power may damage equipments plugged to

EPS, make sure equipment safe before switch to this model.

Off: The unit will interrupt all outlets power output.

*Note: The charger would still work under these four switch modes.

For PIE Series, the unit provides specific Bypass function.

Bypass: The switch provides the bypass for charge only and shutdown the unit when the utility power exceeds 300Vac or

below 140Vac. In charger only mode, battery backup will not work.

10. Power Switch

Used as the master on/off switch for equipment connected to the battery power supplied outlets.

11. Power ON Indicator

This LED is above the power switch. It illuminates when the utility condition is normal and the EPS outlets

are providing power, free of surges and spikes.

12. LCD Display Toggle / Selected Switch

Users can monitor EPS status and set up functions by using the toggle.

13. Multifunction LCD Readout

High resolution and intelligent LCD display shows all the EPS information with icons and messages. For

more information please check the DEFINITIONS FOR ILLUMINATED LCD INDICATORS section.

14. SNMP/DB9/USB Network slot (only PRO Series)

Remove the cover panel to install optional SNMP/DB9/USB CARD that allows remote monitoring and

control of your EPS through network or cable.
