Managing System Backing up and Restoring the Switch
User Guide
13
5
Backing up and Restoring the Switch
With backup and restore, you can:
Save the current configuration.
Restore to the previous configuration.
5.1 Saving the Current Configuration
Choose the menu System > System Tools > Backup and Restore to load the following
page. In the Config Backup section, click Backup Config to save the configuration file to
your PC.
Figure 5-1 Backing Up the Configuration
Note:
It will take several minutes to save the configuration file. Wait without any operation.
