Configuring VLAN Appendix: Default Parameters
User Guide
59
6
Appendix: Default Parameters
Default settings of VLAN are listed in the following tables.
Table 6-1 Default Settings of MTU VLAN Configuration
Parameter Default Setting
MTU VLAN Configuration Disable
Table 6-2 Default Settings of Port Based VLAN Configuration
Parameter Default Setting
Port Based VLAN Configuration Enable
VLAN ID 1
VLAN Member Port 1-5
Table 6-3 Default Settings of 802.1Q VLAN Configuration
Parameter Default Setting
802.1Q VLAN Configuration Disable
Table 6-4 Default Settings of 802.1Q VLAN PVID Configuration
Parameter Default Setting
PVID 1
