Tp-Link TL-SG1024DE V3 [20/86] Rebooting the switch

User Guide 16

Managing System Rebooting the Switch

Rebooting the Switch

Choose the menu System > System Tools > System Reboot to load the following page.

Click Reboot.

Figure 6-1 Rebooting the Switch

Note:

•

It will take several minutes to reboot the switch. Wait without any operation while the switch

reboots.

•

To avoid any damage, do not power down the switch while the switch reboots.
