Appendix
- 79 -
English
Revision History
Appendix B: RealTek AC’97 Audio Driver
Insert the driver CD-title that came with your motherboard into your CD-ROM driver, the driver
CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device
icon in "My computer", and execute the setup.exe.
(3)
(4)
(2)
2.Click "Next".
3.Click "Finish" to restart computer.
(1)
1.Click "Install RealTek AC’97 Driver"
item.
Press "Audio Driver" icon.
