- 80 -GA-8GEMT4 Series Motherboard
English
Appendix C: Intel Network Driver Installation (*)
1.Click "Install Intel Netware
Driver(XP)".
(1)
(2)
(3)
2.Click "Next".
5.Click "Finish" to restart computer.
(4)
(5)
(6)
3.Click "Next".
4.Click "Install".
Press "Network Driver"
icon.
(*) For GA-8GEMT4 only
