![Gigabyte GA-8GEM667K [12/86] Ga 8gem667k motherboard layout](/img/pdf.png)
Gigabyte GA-8GEM667K [12/86] Ga 8gem667k motherboard layout
![Gigabyte GA-8GEM667K [12/86] Ga 8gem667k motherboard layout](/views2/1047492/page12/bgc.png)
- 8 -GA-8GEM667K Motherboard
English
GA-8GEM667K Motherboard Layout
5
2X_DET
Kinnereth-R
SPDIF_O
F_AUDIO
CI
GA-8GEM667K
KB_MS
COMA
LPT
USB
SOCKET478
CPU_FAN
ATX
FDD
VGA
IDE2
IDE1
PWR_LED
PCI3
F_USB2
BIOS
F_PANEL
SYS _FAN
ICH4
F_USB1
GAME
LINE_IN
LINE_OUTMIC_IN
ATX_12V
AGP
DDR2
DDR1
845GE
BAT
PCI1
PCI2
IT8712
CODEC
IR_CIR
WOL
CLR_PWD
LAN
BUZZER
COMB
CD_IN
SUR_CEN
